WELD S70 three-piece forged wheels are a lightweight and affordable solution for American Muscle & other high-performance machines for both the street & strip usage. WELD S70 wheels are available in 15", 17", 18" and 20" diameters and up to 18" wide. Furthermore, the wheels are available in a full polished or black and machined contrast finish.
Part Number Information
Size | Bolt Pattern 1 | Bolt Pattern 2 | Part Number | Finish | Bore | Offset | BSM (in) | Cap Num | Rating (lb) | Beadlock | Lug Type | Lipsize (IN) |
---|---|---|---|---|---|---|---|---|---|---|---|---|
15x8 | 5x4.75 | 70LB508B45F | Black Center - Polished Shell | 80.77 | 0 | 4.5 | P605-5073B | 1580 | Black SBL MT | -- | ||
15x8 | 5x4.75 | 70LP508B45F | Polished Center - Polished Shell | 80.77 | 0 | 4.5 | P605-5073 | 1580 | Black SBL MT | -- | ||
15x9 | 5x4.5 | 70MB509A65F | Black Center - Polished Shell | 80.77 | 38 | 6.5 | P605-5073B | 1580 | Black SBL MT | -- | ||
15x9 | 5x4.5 | 70MP509A65F | Polished Center - Polished Shell | 80.77 | 38 | 6.5 | P605-5073 | 1580 | Black SBL MT | -- | ||
15x10 | 5x4.5 | 70LB510A65F | Black Center - Polished Shell | 80.77 | 25 | 6.5 | P605-5073B | 1580 | Black SBL MT | -- | ||
15x10 | 5x4.75 | 70LB510B75F | Black Center - Polished Shell | 80.77 | 51 | 7.5 | P605-5073B | 1580 | Black SBL MT | -- | ||
15x10 | 5x4.5 | 70MB510A65F | Black Center - Polished Shell | 80.77 | 25 | 6.5 | P605-5073B | 1580 | Black SBL MT | -- | ||
15x10 | 5x4.5 | 70MB510A75F | Black Center - Polished Shell | 80.77 | 51 | 7.5 | P605-5073B | 1580 | Black SBL MT | -- | ||
15x10 | 5x4.75 | 70MB510B55F | Black Center - Polished Shell | 80.77 | 0 | 5.5 | P605-5073B | 1580 | Black SBL MT | -- | ||
15x10 | 5x4.75 | 70MB510B75F | Black Center - Polished Shell | 80.77 | 51 | 7.5 | P605-5073B | 1580 | Black SBL MT | -- | ||
15x10 | 5x120 | 70MB510N75F | Black Center - Polished Shell | 80.77 | 51 | 7.5 | P605-5073B | 1580 | Black SBL MT | -- | ||
15x10 | 5x115 | 70MB510W65F | Black Center - Polished Shell | 80.77 | 25 | 6.5 | P605-5073B | 1580 | Black SBL MT | -- | ||
15x10 | 5x4.5 | 70LP510A65F | Polished Center - Polished Shell | 80.77 | 25 | 6.5 | P605-5073 | 1580 | Black SBL MT | -- | ||
15x10 | 5x4.75 | 70LP510B75F | Polished Center - Polished Shell | 80.77 | 51 | 7.5 | P605-5073 | 1580 | Black SBL MT | -- | ||
15x10 | 5x4.5 | 70MP510A65F | Polished Center - Polished Shell | 80.77 | 25 | 6.5 | P605-5073 | 1580 | Black SBL MT | -- | ||
15x10 | 5x4.5 | 70MP510A75F | Polished Center - Polished Shell | 80.77 | 51 | 7.5 | P605-5073 | 1580 | Black SBL MT | -- | ||
15x10 | 5x4.75 | 70MP510B55F | Polished Center - Polished Shell | 80.77 | 0 | 5.5 | P605-5073 | 1580 | Black SBL MT | -- | ||
15x10 | 5x4.75 | 70MP510B75F | Polished Center - Polished Shell | 80.77 | 51 | 7.5 | P605-5073 | 1580 | Black SBL MT | -- | ||
15x10 | 5x120 | 70MP510N75F | Polished Center - Polished Shell | 80.77 | 51 | 7.5 | P605-5073 | 1580 | Black SBL MT | -- | ||
15x10 | 5x115 | 70MP510W65F | Polished Center - Polished Shell | 80.77 | 25 | 6.5 | P605-5073 | 1580 | Black SBL MT | -- | ||
15x11 | 5x115 | 70MB511W65F | Black Center - Polished Shell | 80.77 | 13 | 6.5 | P605-5073B | 1580 | Black SBL MT | -- | ||
15x11 | 5x115 | 70MP511W65F | Polished Center - Polished Shell | 80.77 | 13 | 6.5 | P605-5073 | 1580 | Black SBL MT | -- |
Size | Bolt Pattern 1 | Bolt Pattern 2 | Part Number | Finish | Bore | Offset | BSM (in) | Cap Num | Rating (lb) | Beadlock | Lug Type | Lipsize (IN) |
---|---|---|---|---|---|---|---|---|---|---|---|---|
17x10 | 5x120 | 70HB7100N72F | Black Center - Polished Shell | 80.77 | 43 | 7.2 | P605-5073B | 1580 | Black SBL | -- | ||
17x10 | 5x115 | 70HB7100W67F | Black Center - Polished Shell | 80.77 | 30 | 6.7 | P605-5073B | 1580 | Black SBL | -- | ||
17x10 | 5x4.5 | 70LB7100A80F | Black Center - Polished Shell | 80.77 | 64 | 8 | P605-5073B | 1580 | Black SBL | -- | ||
17x10 | 5x4.75 | 70MB7100B83F | Black Center - Polished Shell | 80.77 | 71 | 8.3 | P605-5073B | 1580 | Black SBL | -- | ||
17x10 | 5x120 | 70HP7100N72F | Polished Center - Polished Shell | 80.77 | 43 | 7.2 | P605-5073 | 1580 | Black SBL | -- | ||
17x10 | 5x115 | 70HP7100W67F | Polished Center - Polished Shell | 80.77 | 30 | 6.7 | P605-5073 | 1580 | Black SBL | -- | ||
17x10 | 5x4.5 | 70LP7100A80F | Polished Center - Polished Shell | 80.77 | 64 | 8 | P605-5073 | 1580 | Black SBL | -- | ||
17x10 | 5x4.75 | 70MP7100B83F | Polished Center - Polished Shell | 80.77 | 71 | 8.3 | P605-5073 | 1580 | Black SBL | -- | ||
17x10.5 | 5x120 | 70HB7105N77F | Black Center - Polished Shell | 80.77 | 50 | 7.7 | P605-5073B | 1580 | Black SBL | -- | ||
17x10.5 | 5x120 | 70HP7105N77F | Polished Center - Polished Shell | 80.77 | 50 | 7.7 | P605-5073 | 1580 | Black SBL | -- | ||
17x11 | 5x4.75 | 70HB7110B77F | Black Center - Polished Shell | 80.77 | 43 | 7.7 | P605-5073B | 1580 | Black SBL | -- | ||
17x11 | 5x115 | 70HB7110W62F | Black Center - Polished Shell | 80.77 | 5 | 6.2 | P605-5073B | 1580 | Black SBL | -- | ||
17x11 | 5x115 | 70MB7110W58F | Black Center - Polished Shell | 80.77 | -5 | 5.8 | P605-5073B | 1580 | Black SBL | -- | ||
17x11 | 5x4.75 | 70HP7110B77F | Polished Center - Polished Shell | 80.77 | 43 | 7.7 | P605-5073 | 1580 | Black SBL | -- | ||
17x11 | 5x115 | 70HP7110W62F | Polished Center - Polished Shell | 80.77 | 5 | 6.2 | P605-5073 | 1580 | Black SBL | -- | ||
17x11 | 5x115 | 70MP7110W58F | Polished Center - Polished Shell | 80.77 | -5 | 5.8 | P605-5073 | 1580 | Black SBL | -- |
